RTA-164AGC1A Single Port Integrated RJ45 Magjack LPJG17370-1AONL

Name: RTA164AGC1A Single Port Integrated RJ45 Magjack LPJG173701AONL
Brand: LINK-PP
Price: 0.09 USD

Buy cheap RTA-164AGC1A Single Port Integrated RJ45 Magjack LPJG17370-1AONL product

Place of Origin : Guangdong,China

Brand Name : LINK-PP

Certification : UL,ROHS,Reach,ISO

Model Number : LPJG17370-1AONL

MOQ : 50/500/1000/25K

Price : $0.09-$1.85

Packaging Details : 50pcs/tray,1200pcs/carton

Delivery Time : Stock

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 250000-320000/Month

Original : RTA-164AGC1A

Equivalent : LPJG17370-1AONL

Ethernet : 1x1000 Gigabit

Jack : Female RJ45

Samples : Free Available

File : PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters

Contact Now

RTA-164AGC1A RJ45 Single Port LPJG17370-1AONL PCB Connector with Filter Inside

LINK-PP Part Number	LPJG17370-1AONL
Application-Lan	ETHERNET(NoN PoE)
Part Number	RTA-164AGC1A
Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Cores per Port	8
Diodes	NO DIODES
LED Option	Orange&Green/Yellow Leds
Latch	TAB UP
Number of Ports	1X1
PCB Mount Angle	SIDE ENTRY
Package Height (Inches/mm)	0.531/13.50
Package Length (Inches/mm)	1.00/25.4
Package Width (Inches/mm)	0.640/16.25
Pin Type	THT SOLDER
RoHS Compliant	YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search	YES
Shield EMI Tabs	WITH
Speed	10/100 BASE-T
Temperature	0℃ TO 70℃
Turns Ratio RX	1CT:1CT
Turns Ratio TX	1CT:1CT

You may be interesting in below considerate supports:

Datasheet	Request by email to	contact us
Samples	Free	For Free samples delivery, pls advise below infomation For Shipping
		Company Name
		Delivery Address
		Telephone Number
		Contact Person
		UPS/DHL/Fedex/TNT A.C	(If available)
Trial Production	U/P(USD)	$0.09-$1.85	We can ship out parts directly to your warehouse/door to door
	L/T(Weeks)	Stock
	Shipping Term	DAP/CIF/FCA/FOB
Mass Production	U/P(USD)	Stock
	L/T(Weeks)	Stock
	Shipping Term	DAP/CIF/FCA/FOB
	Lifecycel	More than 20 years	You can use our parts for long term consideration
	Reject Ratio	Zero Defective (100% Tested)
Special Services	Accept customized service		Accept revised designing
Now you can contact us instantly

	Turn Ratio(±2%):	TX=1CT:1CT RX=1CT:CT
	Inductance OCL	350uH MIN/@ 100KHz,0.1V,8mA DC Bias
	Insertion Loss	-1.0dB MAX @ 1-100MHz
	Return Loss	-18dB MIN @ 1-30MHz
		-16dB MIN @ 30-60MHz
		-12dB MIN @ 60-80MHz
		-10dB MIN @ 80-100MHz
	Cross talk
	Cross talk	-30dB MIN @ 1-100MHz
	Common Mode Rejection	-30dB MIN @ 1-100MHz
	Hipot Test	1500Vrms MIN
	Operating Temperature Range	0℃ TO 70℃.

1. Tab-down RJ45 Jack LPJG17370-1AONL
2. PCB RJ45 Connectors
3. Network Interface Module Rj45 Jack
4. Hi-pot 1500Vrms

5. LINK-PP Lan Connectors Rj45 With Led Activity

6. Document : PDF / Datasheet / 3D / IGS / Step /Stp

NOTES:

1. Designed to support application,such as SOHO(ADSL modems),

LAN-on-Motherboard(LOM),hub and Switches.

2. Meets IEEE 802.3 specification

3. Connector Materials:

Housing: Thermoplastic UL94V-0

Contact / Shield : Cooper alloy

Shield plating : Nickel

Contact plating: Gold 6 micro-inches min.In contact area.

4. Wave solder tip temperature : 265℃ Max

Wave solder tip temperature Time : 5 Sec Max
